  • What We Do

    Some of the tasks we have completed.

    Power Superyacht Stability - 50m

    We designed and obtained Lloyds' approval for structural changes, which allowed the yacht to operate to its full potential whilst complying with all stability criteria. To Lloyds standards.

    Sail Superyacht LS & Inclining Trail

    Following a lightship inspection and inclining trial, a revised Stability Information Booklet was produced to reflect the yacht's current condition and role. To Bureau Veritas standards

    Pointcloud Data

    Many of our jobs come with point cloud data defining the vessel shape. As well as 3D positions, it lists luminosity and colour, allowing us to work with photo-realistic type information.

  • Drawings for Class and Vessel Catalogue

    We can offer a complete drafting and design service to keep an up to date portfolio of drawings available to ship's masters and officers.



    These can be simple drafting updates to reflect changes in systems or a complete redesign of engineering parts as required.



    Drawings can be generated from existing originals, pdf or scanned data.



    The supply of drawings can be in various formats; the most popular and flexible option is to export a multi-layer pdf file that allows selected information to be printed or hidden. In addition, we can provide data to enable sharing with other contractors.



    Post refit, there are often many drawings to update, including General Arrangements, Fire safety Plans and Lifesaving Plans, and we can help to produce these in an ordered, consistent fashion.
